群豐駿CarUX深耕車用顯示器技術多年，從研發、設計、製造，到系統整合，以及車用內飾工藝服務等各項服務，均可在廠內進行設計、開發和製作，提供全方位的客製化服務。
碩望與群豐駿CarUX攜手致力於汽車顯示器的開發、創新和製造，並在跨界多元的領域中積極擴展，拓展國際市場，建立具有韌性的供應鏈，為產業帶來更多跨界多元的發展機會。
多種尺寸選擇
· 提供7吋到12.3吋的選擇，以滿足不同需求和應用場景。
內嵌式觸控技術
· 搭載 In-cell Touch 內嵌式觸控技術，實現了更窄、更薄的面板邊框，使其與車裝內部完美融合，提升了一體化效果。
精緻畫質
· 相較於消費性電子產品，現今的車用畫質表現上達到了更高水準，展現出更加逼真且高畫質的顯示效果，讓圖像呈現精緻而清晰。
客製化服務
· 根據客戶需求的定制服務，以滿足個別客戶的特殊需求和喜好。
歡迎查看下方尺寸表、了解基本功能架構, 從中尋找最貼近您的需求項目,如果有其他相關需求或須更進一步諮詢,請與我們聯繫，我們將提供您更全面的服務!
| Size | 7" | |||
|---|---|---|---|---|
| Model Name | JE070IA-18J | JJ070IA-18L | AT070TN94 | DJ070IA-20B |
| Product type | FOG | Module | Module | Module |
| Resolution | 800 x 3(RGB) x480 | 1280 x 3(RGB) x768 | ||
| Aspect Ratio | 15:9 | 16:9 | 15:9 | |
| Active Area | 152.4 x 91.44 | 154.08 x 85.92 | 152.45 x 91.47 | |
| Display Technology | IPS | TN | IPS | |
| Viewing Angle (Tpy.) | 85/85/85/85 (typ) | 50/70/70/70 (typ) | 85/85/85/85 (typ) | |
| Luminance (nits) | NA | 600 (min), 750 (typ) | 400 (min), 500 (typ) | 750 (min), 930 (typ) |
| Interface | Parallel 24bit RGB | LVDS | Parallel 24bit RGB | LVDS |
| Operation Temperature (℃) | -30~85 | -30~85 | -30~85 | |
| Storage Temperature (℃) | -40~90 | -30~85 | -40~90 | |
| Size | 8" | |||||
|---|---|---|---|---|---|---|
| Model Name | JJ080IA-15A | DJ080IA-10A | NJ080IA-10D | DJ080IA-11A | DD080IA-20A (S20) | 8" TID FOG (S20) |
| Product type | Module | FOG(not ready) | ||||
| Resolution | 800 x 3(RGB) x 480 | 1024 x 3(RGB) x 600 | 1280 x 3(RGB) x 720 | |||
| Aspect Ratio | 15:9 | 16:9 | 16:9 | |||
| Active Area | 174 x 104.4 | 176.64 × 99.36 | 176.64 × 99.36 | |||
| Display Technology | IPS | IPS | IPS | IPS, TID (in-cell touch) | ||
| Viewing Angle (Tpy.) | 85/85/85/85 (typ) | |||||
| Luminance (nits) | 750 (min), 920 (typ) | 600 (min), 750 (typ) | 400 (min), 500 (typ) | 600 (min), 750 (typ) | 570 (min), 700 (typ) | NA |
| Interface | LVDS | |||||
|
Operation Temperature (℃) |
-30~85 | -20~70 | -30~85 | |||
|
Storage Temperature (℃) |
-40~90 | -30~85 | -40~90 | |||
| Size | 9" | |
|---|---|---|
| Model Name | DD090IA-05A (S20 TID) | 9" TID FOG (S20) |
| Product type | Module | FOG |
| Resolution | 1280 x 3(RGB) x 720 | |
| Aspect Ratio | 16:9 | |
| Active Area | 198.912 x 111.888 | |
| Display Technology | IPS, TID (In-cell touch) | |
| Viewing Angle (Tpy.) | 85/85/85/85 (typ) | |
| Luminance (nits) | 800 (min), 1000 (typ) | NA |
| Interface | LVDS | |
| Operation Temperature (℃) | -30~85 | |
| Storage Temperature (℃) | -40~90 | |
| Size | 10.1" | |
|---|---|---|
| Model Name | DE101IA-07P | DJ101IA-07A |
| Product type | FOG | Module |
| Resolution | 1280 x 3(RGB) x 720 | |
| Aspect Ratio | 16:9 | |
| Active Area | 223.68 × 125.82 | |
| Display Technology | IPS | |
| Viewing Angle (Tpy.) | 85/85/85/85 (typ) | |
| Luminance (nits) | NA | 600 (min), 750 (typ) |
| Interface | LVDS | |
| Operation Temperature (℃) | -30~85 | |
| Storage Temperature (℃) | -40~90 | |
| Size | 10.25" | ||||
|---|---|---|---|---|---|
| Model Name | JE103IA-10A | JJ103IA-12A (S20) | JE103BC-12B(S20) | DJ103KC-01A (S20) | 10.25" TID FOG (S20) |
| Product type | FOG | Module | FOG | Module | FOG |
| Resolution | 1920 x 3(RGB) x720 | ||||
| Aspect Ratio | 8:3 | ||||
| Active Area | 243.648 × 91.368 | ||||
| Display Technology | IPS | LTPS, IPS, TID (in-cell touch) | |||
| Viewing Angle (Tpy.) | 85/85/85/85 (typ) | ||||
| Luminance (nits) | NA | 640 (min), 800 (typ) | NA | 800 (min), 1000 (typ) | |
| Interface | LVDS | ||||
| Operation Temperature (℃) | -30~85 | ||||
| Storage Temperature (℃) | -40~90 | ||||
| Size | 12.3" | |||
|---|---|---|---|---|
| Model Name | DJ123IC-02A (S20) | DE123DC-02B (S20) | DJ123KC-01A (S20) | 12.3" TID FOG (S20) |
| Product type | Module | FOG | Module | FOG |
| Resolution | 1920 x 3(RGB) x 720 | |||
| Aspect Ratio | 8:3 | |||
| Active Area | 292.032 × 109.512 | |||
| Display Technology | LTPS, IPS | LTPS, IPS, TID (in-cell touch) | ||
| Viewing Angle (Tpy.) | 85/85/85/85 (typ) | |||
| Luminance (nits) | 800 (min), 1000 (typ) | NA | 800 (min), 1000 (typ) | NA |
| Interface | LVDS | |||
| Operation Temperature (℃) | -30~85 | |||
| Storage Temperature (℃) | -40~90 | |||
